Shrink Fit HYDRAULIC CHUCK HC
Holder

Milling
Chuck

SK Slim
Chuck

ER Collet
Chuck

N&COHDtorhilldel reCTrhsouoclk CBT Taper G Value RPM Run-Out Coolant
Accuracy (at 3D) System

CBT (BT 2면 구속형) AT3 2.5 25,000 ≤3Um AD

Morse Taper Unit : mm

Arbor TAPER No. MODEL No. d1 D1 D2 L L1 L2 G 중량(Kg) 재고
30 CBT30-HC6-70 6 26
CBT30-HC8-70 8 28 44.5 70 29.5 27 M5x0.8 0.65
40 CBT30-HC10-75 10 30
CBT30-HC12-85 12 32 44.5 70 30 27 M6x1.0 0.65
CBT30-HC14-85 14 34
CBT30-HC16-90 16 38 44.5 75 31 32 M8x1.0 0.73
CBT30-HC18-90 18 40
Tapping ChuckSynchro CBT30-HC20-90 20 42 45 85 45 37 M10x1.0 0.80 ●
CBT40-HC6-90 6 26
CBT40-HC8-90 8 28 45 85 45 37 M10x1.0 0.80
CBT40-HC10-90 10 30
CBT40-HC12-90 12 32 45 90 50 42 M10x1.0 0.90
CBT40-HC14-90 14 34
CBT40-HC16-90 16 38 45 90 50 42 M10x1.0 0.90
CBT40-HC18-90 18 40
Tapping ER CBT40-HC20-90 20 42 45 90 50 42 M6x1.0 0.90 ●
Chuck CBT40-HC25-100 25 50
CBT40-HC32-105 32 60 44.5 90 43 27 M5x0.8 1.30

44.5 90 44.5 27 M6x1.0 1.30

44.5 90 44.5 32 M8x1.0 1.35

44.5 90 44.5 37 M10x1.0 1.35 ●

Tapping 44.5 90 44.5 37 M10x1.0 1.35
Chuck
44.5 90 47.5 42 M12x1.0 1.40

44.5 90 47.5 42 M12x1.0 1.45

44.5 90 47.5 42 M16x1.0 1.50 ●

Side Lock Arbor 60 100 47.5 48 M16x1.0 1.70
& End Mill Holder
60 105 - 55 M16x1.0 2.10 ●

▶ CAT(ANSI B5.50) Taper 및 Inch Type 제품 공급 가능
