MIRAEPO NC TOTAL TOOLING SYSTEM

▣ 백 보링 커터 (편심 타입)

Back Boring Cutter Bar
(백 보링 커터 바)

insert

∅d3 ∅D1

∅d2 ∅d1 L1
L
L2 L3

규격 d1 d2 d3 D1 L1 L2 L3 L 적용insert 가격
151,200
ST32-BBM2241-200 22.0 41 22.0 154,000
162,200
ST32-BBM2443-200 24.0 43 24.0 85 15 SP 11 173,200
176,000
ST32-BBM2646-200 26.0 46 26.0 182,800
195,200
ST32-BBM2850-200 28.0 50 28.0 198,000
213,100
ST32-BBM3052-200 30.0 52 30.0 83 17 SP 14 229,600
233,700
ST32-BBM3254-200 32.0 54 32.0 32 100 200 162,200
165,000
ST32-BBM3462-200 34.0 62 34.0 173,200
184,200
ST32-BBM3664-200 36.0 64 36.0 187,000
193,800
ST32-BBM3866-200 38.0 66 38.0 85 15 AP 16 206,200
209,000
ST32-BBM4072-200 40.0 72 40.0 224,100
240,600
ST32-BBM4274-200 42.0 74 42.0 244,700

ST42-BBM2241-200 22.0 41 22.0

ST42-BBM2443-200 24.0 43 24.0 85 15 SP 11

ST42-BBM2646-200 26.0 46 26.0

ST42-BBM2850-200 28.0 50 28.0

ST42-BBM3052-200 30.0 52 30.0 83 17 SP 14

ST42-BBM3254-200 32.0 54 32.0 42 100 200

ST42-BBM3462-200 34.0 62 34.0

ST42-BBM3664-200 36.0 64 36.0

ST42-BBM3866-200 38.0 66 38.0 85 15 AP 16

ST42-BBM4072-200 40.0 72 40.0

ST42-BBM4274-200 42.0 74 42.0
